Glazed Aluminum Curtain Wall Profile

Glazed aluminum curtain walls are a major architectural product in modern urban buildings, used in large-scale structures such as commercial and office buildings, as well as airports. Aluminum curtain walls are increasingly used in buildings due to their lightweight, high rigidity, high strength, oxidation resistance, corrosion resistance, long service life, high plasticity, and diverse appearance. Shenghai Aluminum is a manufacturer of aluminum curtain wall profiles, and over 18+ companies from countries including the United States, Australia, Saudi Arabia, Dubai, and Mexico use our aluminum frame curtain wall profiles. Our curtain wall profiles are mainly extruded from 6000 series aluminum alloy, and then surface treatment according to customer requirements (anodizing, powder coating, PVDF coating, etc.). Generally, customers customize aluminum curtain wall profiles based on the usage environment and local climate. Shenghai Aluminum has a comprehensive aluminum curtain wall profile system. If you are looking for aluminum curtain wall profile supplier, please contact us immediately to get a catalog and solutions.

Types of Aluminum Curtain Walls
There are many types of aluminum curtain walls, including these
Glazed aluminum curtain wall
Aluminum glass curtain wall
Aluminum panel curtain wall
Aluminum stone curtain wall
Aluminum photovoltaic curtain wall
Honeycomb aluminum panel curtain wall

Product Application

Our Factory

PE film for each profile/ Shrink PE film for each bundle, Slot packing, Craft paper/ Foam Paper/Carton box

Material & Temper	Alloy 6063-T5,6061-T6 , We will never use aluminum scrap.
Surface Treament	Mill-Finished, Anodizing, Powder Coating, Electrophoresis, Wood Grain, Polishing, Brushing, etc.
Colour	Silver, Champage, Bronze, Golden, Black, Sand coating, Anodized Acid and alkali or Customized.
Film Standard	Anodized:7-23 μ , Powder coating: 60-120 μ , Electrophoresis film: 12-25 μ.
Lifetime	Anodized for 12-15 years outdoor, Powder coating for 18-20 years outdoor.
MOQ	500 kgs. Usually 10-12 tons for a 20'FT; 20-23 tons for a 40HQ.
Length	5.8M or Customized.
Thickness	0.4mm-20mm or Customized.
Application	Building and Construction and Decoration.
Extrusion Machine	600-3600 tons all together 6 extrusion lines.
Capability	Output 1200 tons per month.
Profile type	1. Sliding window and door profiles; 2. Casement window and door profiles; 3. Aluminum profiles for LED light; 4. Tile Trim Aluminum profiles; 5. Curtain wall profile; 6. Aluminum heating insulation profiles; 7. Round/Square General profiles; 8. Aluminum heat sink; 9. Others Industry profiles.
New Moulds	Opening new mould about 7-10 days, absolutely moulds cost can be refund.
Free Samples	Can be available all the time, about 1 days can be sent.
Fabrication	Die designing→ Die making→ Smelting & alloying→ QC→ Extruding→ Cutting→ Heat Treatment→ QC→ Surface treatment→ QC→ Packing→ QC→ Shipping→ After Sale Service
Deep Processing	CNC / Cutting / Punching / Checking / Tapping / Drilling / Milling
Certification	1. ISO9001-2008/ISO 9001:2008; 2. GB/T28001-2001(including all the standard of OHSAS18001:1999); 3. GB/T24001-2004/ISO 14001:2004; 4. GMC.
Payment	1. T/T: 30% deposite, the balance will be paid before delivery; 2. L/C: the balance irrevocable L/C at sight.
Delivery time	1. 15 days production ; 2. If opening mould, plus 7-10 days.
OEM	Available.

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Impurity		Al
									Unit	Total
6063	0.2-0.6	<0.35	<0.1	<0.1	0.45-0.9	<0.1	<0.1	<0.1	<0.05	<0.15	Surplus
6061	0.4-0.8	0.7	0.15-0.4	<0.15	0.8-1.2	0.04-0.35	<0.25	<0.15	<0.05	<0.15	Surplus
6005	0.6-0.9	<0.35	<0.1	<0.1	0.4-0.9	0.1	<0.1	<0.1	<0.05	<0.15	Surplus
6060	0.3-0.6	0.35-0.6	0.1-0.3	<0.1	<0.1	<0.15	<0.05	<0.1	<0.05	<0.15	Surplus
